Brief Introduction of Industrial Roll Heat Press

With the fast-paced development of society, washing equipment has also reached a new height. As far as the current industrial ironing machine is concerned, it has been able to adjust the ironing time and speed according to the thickness of the fabric to be ironed and the difference between the fabrics. The following is an introduction to the characteristics of industrial roller presses.

The main features of the roller press:

• The roller press is a horizontal box-type structure at both ends. The roller is made of high-quality stainless steel plate, which has fast heat transfer, smooth ironing, and no pollution or damage to the linen.

• The transmission, inlet and drainage systems of 2 roller presses are placed in the boxes on both sides respectively. The appearance is beautiful and novel, the structure is compact and the volume is small.

• The roller press is safe and reliable. The feeding part is equipped with a limiting mechanism. When conveying, the hand touches the finger guard and stops immediately to ensure the safety of the operator.

• The roller press sets the corresponding speed difference between the different levels of the conveying system, making the fabric easier to tension and flatten.

• The 5-roller drive system is driven by the motor through the reducer and chain drive, with strong overload capacity, certain buffering and vibration reduction performance, and each chain has a tensioning device, which is convenient to adjust the tightness.

• The 6-roller is conveyed by a wide split belt, separated by a spacer, which avoids the swimming phenomenon that is difficult to solve during transportation. At the same time, it is connected by a micro hasp, which is convenient for disassembly and replacement.

• The steam inlet of the roller press is equipped with a safety valve, which has been calibrated before leaving the factory. It is generally not necessary to adjust during normal work, and the user must send it to the labor department for calibration once a year.

• Each conveying layer of the roller press is separated by a high temperature resistant micro-conducting belt to ensure that the fabric will not stick, so the sizing fabric can also achieve satisfactory ironing results.

Instructions for use of industrial roller press:

• Before ironing the fabric, clean the surface of the drum, then wipe the surface of the drum and various parts of the machine with a soft cloth to ensure that the machine is clean.

• The motor and its control part must pass the insulation inspection to check whether the idling machine is running normally.

• Check whether the oil hole is unblocked, inject an appropriate amount of lubricating oil, and add an appropriate amount of No. 20 or No. 40 oil into the reducer.

• Adjust the conveyor belt to make sure its tension is moderate, not too tight or too loose.

• For the steam-heated roller press, first open the steam shut-off valve next to the steam trap, then open the steam inlet valve, and then close it after the residual water in the steam drum is emptied; then open the speed-regulating motor or inverter controller, Slowly turn the knob, run the roller press at a low speed of 2~3m/min, and at the same time fully open the steam inlet valve, heat the roller, observe the pressure indication value on the left box of the roller press, and wait until the steam pressure reaches 0.3MPa or more Then start ironing.

Notes for industrial roller presses:

• When adjusting the speed of the roller press with the speed-regulating motor and the inverter control knob, it should be adjusted slowly and evenly to avoid sharp rise and fall to ensure its service life.

• Since the roller press is a high-temperature equipment, after work, the roller press should run at low speed with the heat source turned off until its drum is completely cooled, to avoid high temperature conditions for a long time (electrically heated roller press is more serious ) and shorten the service life of each guide belt.

• Pay attention to all valves, gauges and ironing speed during use and operation, and wax with wax remover every day to prevent the surface of the roller press and ironing roller from being astringent. The purpose of waxing is to smooth the surface of the roller press and prevent the parts from wrinkling.

• When the roller press is damaged, the laundry room should be replaced in time to ensure the output effect.

If you are looking for a Wholesale Industrial roll heat press,Industrial roll heat press Manufacturer,Industrial roll heat press supplier, we hope we will be your best choice.
