Failures and methods of roller heat transfer machine(Recommended)
July 21,2021
No matter what printing machine is used, we will care for the machine, and the roller heat transfer machine is no exception. As a multifunctional garment digital printing machine, the roller thermal transfer machine needs to pay attention to some safety matters during the use of the machine. Once the following failures occur, we must stop the machine.
Understand important parameters
| Mine diameter | ф420mm | ф480mn | ф600nn | ф800nn | ф1000mm |
| Working power supply | Three-phase four-wire, 380V | Three-phase four-wire, 380V | Three-phase four-wire, 380V | Three-phase four-wire, 380V | Three-phase four-wire, 380V |
| Wedding power | 18KW | 18KW~27KWK(Adjustable) | 20KM~36KW(Adjustable) | 33KM~55KW(Adjustable) | 55KM~80KW(Adjustable) |
| Speed adjustment range | 0~3m/min (manual adjustment) | 0~4m/min (manual adjustment) | 0~5m/min (manual adjustment) | 0~6m/min (manual adjustment) | 0~10m/min (manual adjustment) |
Failure & Method
Failure |
Method |
| If a thermal camera fails and you stop for a long time | Please immediately connect the guide cloth or belt and close the steam valve to relieve the pressure of the flower tube. |
| When textiles are being printed, if the sewing head is broken due to poor or too large sewing heads, or even when the cloth heads are placed on other accessories or orders, the machine is likely to have a major failure | The machine should be stopped immediately for processing. Remember that the sooner it happens, the more serious it is |
| When the squeegee appears popular, it will produce streaks, and the blunt blade will cause the squeegee to be unclean and the pattern to be rough or not to appear | Normally, we need to suppress the spray painting and replace it with a new one |
| After the hot-loaded printing long-tube machine has a long-cylinder flower tube used for too long, make the inner hole tube, make the tube shaft and the flower tube loose so that the flower tube does not move properly | The sleeve should be removed, the paper strip should be put on the sleeve, and the sleeve should be tightened |
| The flower tube bearing is damaged in operation and heats up. When installing the bearing, use the cold to pour the bearing | You should stop immediately, replace the flower tube bearing with a good one, and add good lubricating grease |
The above five points are the most common failures of the digital printing machine in the digital printing machine. If the machine fails, we will fix the problem and dye it. Any technic to roller heat transfer machinem, welcome to contact us.
